      SQSL1

      LED Square Sports Lighting

      • 7 Year Warranty
      • IP65
      • UL Certified
      • 7 Year Warranty
      • FC
      • European Conformity

      The SQSL1 LED square sports light will give you the game-changing performance you need to professionally illuminate any sports venue. With multiple optics and mounting options, you’ll get the light exactly where it’s needed the most - right in the middle of the action! If you are ready for the next level of athletic performance, there are additional intelligent lighting controls available.

      Data Sheet IES File Installation Guide

      Product Specs

      Color Temperatures:
      4000K, 5000K, 5700K
      Max Lumens:
      271884
      Voltage:
      120-277V, 277-480V
      Wattage:
      500W, 600W, 1000W, 1200W, 1500W, 1800W
      Accessories:
      Light Shield, Wireless Control, Casambi DMX Control, Aiming Laser

      Product Details

      Key Features

      • Combines superior performance and advanced thermal management in an appealing square design.

      • Excellent uniformity that accurately renders true colors on the sports field.

      • Versatile mounting options provide operational flexibility for any outdoor installation.

      • Additional intelligent lighting controls and monitoring capabilities available.

      Construction

      • Rugged die-cast aluminum design protects integral components from harsh environments and optimizes thermal management.

      • Housing is protected by a corrosion resistant powder coat finish.

      • IP65 rated optics offer protection from outdoor conditions.

      • LED driver is mounted in contact with the casting to assist low operating temperatures and maintain long life.

      Electrical

      • 120-277V or 277-480V available.

      • 0-10V dimming standard.

      • Operating temperature: -40°C to 45°C (-40°F to 113°F)

      Optics

      • Industry leading LEDs with 4000K, 5000K, and 5700K CCT (minimum 70 CRI).

      • Lumen Maintenance: 162,000 Hours (L70).

      • Choice of precision-molded optics.

      Mounting

      • Trunnion or adjustable slip fitter mount options available.

      Warranty

      • Backed by US LED's Five-Year Warranty.

      Stocked Configurations

      SQSL1 in-stock configurations are subject to change at any time. Please contact customer service for the most recent list of stocked configurations.
